Model Name | PANZER MAX |
---|
Case Form Factor | Full-Tower |
---|
Dimension (WxHxD) | 266 x 612 x 556 (mm) 10.47 x 24.09 x 21.88 (in) |
---|
Motherboard Type | Mini ITX / Micro ATX / ATX / CEB / E-ATX ( E-ATX up to 12"x11" ) |
---|
5.25" Drive Bay | 2 |
---|
3.5" Drive Bay | 2 |
---|
2.5" Drive Bay | 4+2 (converted from 3.5" drive bays) |
---|
Expansion Slots | 8 |
---|
Cooling System | Front | 120mm x 3 / 140mm x 3 120mm x 2 (Standard (non-LED) Fan Preinstalled) |
---|
Top | 120mm x 3 / 140mm x 2 |
---|
Rear | 120mm x 1 (Standard (non-LED) Fan Preinstalled) |
---|
Bottom | 120mm x1 / 140mm x 1 |
---|
I/O Panel | USB3.0 x 2/USB2.0 x 2 Mic x 1/Audio x 1 Fan Controller |
---|
Water Cooling Support | Front | 360mm / 280mm / 240mm / 140mm / 120mm |
---|
Top | 360mm / 280mm / 240mm / 140mm / 120mm |
---|
Rear | 120mm x 1 |
---|
Bottom | 140mm x 1 / 120mm x 1 |
---|
Max. Graphics Card Length | 390mm / 15.35 (in) |
---|
Max. CPU Cooler Height | 170mm / 6.69 (in) |
---|
PSU | Standard ATX PS2 |
---|
Max. PSU length | 220 (mm) / 8.7 (in) |
---|
Cable Management | Yes |
---|
Maximum Number of Fans | 8 Max. |
---|
