Model Number | MCC-C700M-MG5N-S00 |
Series | COSMOS Series |
Size | Full Tower |
Available Color(s) | Grey, Silver, Black |
Materials | Steel |
Materials - Side Panel | Curved Tempered Glass, Steel |
Dimensions (L x W x H) | 650 x 306 x 651mm / 25.6 x 12.0 x 25.6inch |
Weight | 22.2 kg |
Motherboard Support | E-ATX, ATX, Micro ATX, Mini ITX |
Expansion Slots | 8 |
5.25" Drive Bays | 1 |
2.5" / 3.5" Drive Bays (Combo) | 4+1 (in the accessory box) |
2.5" Drive Bays | 4 |
I/O Port - USB Ports/ USB 3.1 Type-C | 1 |
I/O Port - USB Ports/ USB 3.0 Type-A | 4 |
I/O Port - Audio - 3.5mm Headset Jack (Audio + Mic) | 1 |
I/O Port - Audio - 3.5mm Mic Jack | 1 |
I/O Port - Fans/Lighting | Fan Speed Control Button, ARGB Control Button |
Pre-Installed Fans - Front | 3x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin) |
Pre-Installed Fans - Rear | 1x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin) |
Fan Support - Front | 3x 120/140mm |
Fan Support - Top | 3x 120/140mm |
Fan Support - Rear | 1x 120/140mm |
Fan Support - Bottom | 2x 120/140mm (bracket needed) |
Radiator Support - Front | 120mm, 140mm, 240mm, 280mm, 360mm, 420mm (requires removal of ODD cage) |
Radiator Support - Top | 120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD, maximum thickness clearance 70mm) |
Radiator Support - Rear | 120mm, 140mm |
Radiator Support - Bottom | 120mm, 140mm, 240mm |
Clearance - CPU Cooler | 198mm |
Clearance - GFX | 490mm (w/o 3.5" HDD BRK), 320mm (w/ 3.5" HDD BRK) |
Note | This PCI-E riser cable inside C700M is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation. |
