Model Name | X299 PRO 10G |
CPU Support | Supports Intel® Core™ X-Series Processor 10000/9000/78xx(above)series for LGA2066 Socket |
CPU Socket | LGA 2066 |
Chipset | Intel® X299 Chipset |
Graphics Interface | 4 x PCI-E 3.0 x16 slots Support 3-way AMD® CrossFire™ Technology Support 3-way NVIDIA® SLI™ Technology |
Memory Support | 8 DIMMs, Quad Channel, DDR4-4200MHz (OC) |
Storage | 2 x Turbo M.2 slots, supports Intel® OptaneTM Technology 6 x SATA 6Gb/s |
USB ports | 1 x USB 3.2 (Gen2 x2, 20G, Type-C) + 1 x USB 3.2 Gen2 (Type-C) + 8 x USB 3.2 (Gen1, Type-A) + 8 x USB 2.0 |
LAN | Realtek RTL8125-CG 2.5G LAN + Intel® I219-V Gigabit LAN |
Audio | 8-Channel(7.1) HD Audio with Audio Boost 4 |
